Product Details:
|
| Type: | Drilling Hammer | Machine Type: | Drilling Tool |
|---|---|---|---|
| Use: | DTH Drilling | Processing Type: | Forging |
| Material: | Carbon Steel | Application: | Rock Drilling |
| Color: | Blue,Gold,Red,Golden,blue Or Customized | Advantage: | High Performance,high Performance And Factory Price |
| Product Name: | Rock Drilling Dth Bits For Minging And Water Well | Usage: | Water Well |
| Connect Thread: | API 2 3/8" API 3 1/2" API 4 1/2" API 6 5/8" REG | Air Pressure: | High Pressure 1.0-2.5 Mpa |
| High Light: | 18 Inch down hole hammer bits,NUMA180 down hole hammer bits,NUMA180 down hole hammer drill bits |
||
Product name:18 inch high air pressure pneumatic dth hammer with NUMA 180 shank for water well drilling
Connection thread: API 8-5/8”REG
Working pressure(bar): 7~25
Outer diameter(mm): 410
Weight(KGS): 1700
Bit diameter recommend(mm): 460~660
High air pressure DTH hammer with NUMA180 shank details:
Kingdrilling has become The Driller’s Choice for some of the world’s small and middle mining projects, thanks to a reliable quality and high cost performance that can supply and service Kingdrilling products in even the most remote and inaccessible parts of the world.
For these customers, Kingdrilling offers a complete range of industry-leading drilling products for exploration, mining, DTH, Piling, water well drilling and blasting operations.
This strong supply chain is backed up by Kingdrilling’s dedication to its AIM principle: reliable, implement and responsibility. Using this, we are able to meet the drilling needs of our Mining and Quarrying customers, while ensuring maximum efficiency and productivity.
Kingdrilling DTH hammer feature:
1. Patented innovation to ensure maximum energy transfer
2. Simplified design for easier servicing and higher reliability
3. high-frequency design for smoother operation
4. Multi-start threads on backhead and chuck for easy coupling/uncoupling
5. Specialised heat-treatment hardening for critical components for maximum longevity
High air pressure DTH hammer with NUMA180 shank technical parameters:
| Model | OD(mm) | Hole range(mm) | Length(mm) | Connection Thread |
Working pressure(Bar) | Air Consumption CFM |
Weight(Kg) |
| MH120P | 275 | 302~460 | 1880 | API6-5/8”REG | 7~25 | 700--1925 | 700 |
| MH180P | 410 | 460~660 | 2210 | API8-5/8”REG | 7~25 | 1200--3000 | 1700 |
| MH240P | 525 | 610~860 | 2300 | API8-5/8”REG | 7~25 | 2000--7000 | 2680 |
| MH240PS | 525 | 860-1100 | 2600 | 120H HEX | 7~25 | 2000--7000 | 3200 |
| MH330P | 718 | 900~1200 | 2100 | 240 HEX | 7~25 | 2625--7700 | 5500 |
How to order?
Shank Type + Top Sub Thread + (With/Without Valve, if this parameter is optional)
Kingdrilling rock drill tools application:
1. mininig,quarry blasting hole borehole drilling
2. water well,depep hole well,oil and gas open hole drilling
3. foundation and piling drilling
4. mininig,quarry blasting hole borehole drilling
FAQ:
1. What is hole hammer?
Pneumatic down-the-hole (DTH) hammer is a pneumatic drilling tool using compressed air as a power source. It is suitable for drilling in pebble, gravel, and hard rock strata. It is often used in building pile foundation construction, bridge, mining, geological exploration, hydrological wells, and other fields.
2. Is top hammer drilling vs down-the-hole drilling?
The primary difference between the top hammer and down-the-hole drilling methods is where the hammer is attached. The hammer in the industrial equipment makes contact with the bit during the down-the-hole drilling method. The top hammer drilling method's activity is concentrated at the very top of the drill string.
3. What is a top hammer used for?
Top hammer drills are primarily used in mining, construction and quarrying of rock material. Top hammer drilling, combined with the “drill and blast” method, makes the whole excavation process extremely efficient.
