U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling

Certification
China Wuhan Kingdrilling Diamond Co.,Ltd certification
China Wuhan Kingdrilling Diamond Co.,Ltd certification
Customer Reviews
hello, we have received the goods, I tried them on and I am satisfied, I would like to order another product,

—— Pavol

I'm Online Chat Now

U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling

U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling
U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling

Large Image :  U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling

Product Details:
Place of Origin: CHINA
Brand Name: MING
Certification: ISO9001
Model Number: U85-11Z
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: 99-99999USD/PC
Packaging Details: WOODEN CASE
Delivery Time: 3-5WEEKS
Payment Terms: T/T, D/P, Western Union
Supply Ability: 2000PCS/MONTH

U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling

Description
Material: High Carbon Steel,Tungsten Carbide,steel Use: Metal Drilling,rock Drilling
Product Name: Ingersoll-Rand Shank Adapters YH65 YH80 YH65RP YH70RP YH75RP YH80RP Application: Drilling Holes
Color: Red/Blue/Black/golden,according To Customer's Requirement,Request Name: Coal Picks
Process: Forging,Fully Ground Quality: Stable And Reliable,best Quality
Machine Type: Drilling Tool Hardness: HRC50-55
High Light: Coal Mining Bits Teeth, Coal Mining Picks, Coal Mining Teeth

Product name: U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling

Other name: Coal cutter picks

Product category: mining picks

Type: U85

Shank Diameter: 30mm



KINGDRILLING mining cutter picks description:

A coal mine's hardness, the kind of coal pick holder it uses, and other elements determine the coal mining bit. Separate categories for the coal mining bits are U82, U84, U85, U92, U94, U95, U170, and so on.

One worn-out component of the coal mining equipment is the coal pick. After conducting extensive research on picks, the company evaluated the dependability of coal mining picks from multiple angles, including new pick selection, pick arrangement, and pick structure enhancement to boost pick dependability, lower the percentage of tooth loss in the cost per ton of coal, and extend the effective working time of shearers.



KINGDRILLING Coal mining bit usage:
Coal mining bit usage: mainly used for coal mining and roadway, tunnel, ground trenching and other projects, equipped with shearers, boring machines, milling machines and other equipment.



KINGDRILLING mining cutter picks parameters:

Catalog No. Shank Diameter
mm
Shoulder Diameter
mm
Button Size
mm
Overall Length
mm
Tines Length
mm
U85-16G 30 16 56 161 85
U85-12Z 30 12 56 162 86
U85-19G 30 19 51 150 78
U85-11Z 30 11 51 161 84
U85-14G 30 14 51 149 77
U85-18G 30 18 65 164 89
U92-16G 35 16 55 225 89
U92-25G 35 25 55 183 89
U92-12Z 35 12 55 236 100
U92-22G 35 22 55 237 100
U92-19G 35 19 55 195 102
U92-16Z 35 16 55 195 102
U94-19G 35 19 55 183 89
U94-19Z 35 19 55 182 88
U94-17Z 35 17 55 189 95
U94-19D 35 19 55 176 82
U95-25G 35 25 55 183 89
U95-22G 35 22 55 180 87
U95-25D 35 25 55 184 89
U95-22D 35 22 55 180 89
U170-25Z 43 25 64 221 89
U170-22Z 43 22 64 234 102
U170-22G 43 22 64 234 102
U170-19G 43 19 64 246 114
U170-25G 43 25 64 234 102
U170-22G 43 22 64 246 114




Kingdrilling coal picks advantage:

1. Achieve unparalleled drilling efficiency with our Coal Mining Picks, ensuring stable and reliable drilling speed every time.

2. Customization is at the core of our design, making it possible to tailor the bit to your specific drilling needs for maximum effectiveness and precision.

3. Count on a long service life with our Coal Mining Picks, constructed with high-quality raw materials that guarantee durability and consistent performance.

4. Stay within budget without compromising on quality – our competitive price point makes it accessible for projects of any size without sacrificing efficiency.

5. Experience the superior performance of our Coal Mining Picks, suitable for a wide range of applications and backed by our dedicated customer support for a worry-free experience.



Why you should choose us as your reliable cutting teeth supplier?

In order to better serve our customers and provide solutions that are appropriate for their needs, KINGDRILLING mining cutter pick has always appreciated direct customer feedback.

We value client input, and it is our goal to consistently outperform ourselves in the production of high-quality goods through our unwavering efforts.We don't produce low-quality goods and provide low costs to entice customers in an effort to establish a long-term business partnership.

KINGDRILLING prioritizes quality. We carry out stringent inspections both during and after production to ensure quality.We may tailor our services to your specific needs. For example, we can choose the appropriate tungsten carbide tips for your various hard rock conditions.



In the passion we carry our cutting teeth will help our customers to make more money when using our teeth over bigger companies that don't know or care about individual customer requirement.



FAQ:

1. How to order the products?

A: Please send the inquiry with detail item description or with Model number.

2. How about the common packing?
A: If there is no special packing demand, we will take it as our normal packing. First in small carton, and then put in the bigger carton together to make sure goods completed.

3. Can I expect a quality products?
A: Yes. mature production technology ensuring the quality satisfy international request.

4. How to check the product are the exact one you want?
A: If possible, please attach one reference picture to avoid any misunderstanding or any links from our website for a better understanding.

5. How to control quality?
A: We have our own experienced QC team,there will be strict inspection and testing for each order before shipping out.

6. Fast delivery time:
A: Usually it takes 25 days for production.only 3 or 5 days if we have stock of your request size.

7. Shipping way:
A: Sample order: we suggest Courier express delivery such as DHL/UPS/TNT/FEDEX or by air
Bulk order: by air or by sea we suggest.

8. Competitive price:
A:KINGDRILLING factory can supply you the lowest price due to direct sale to customers without distributor!



More information:

U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling 0U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling 1U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling 2

U85 30mm Shank Diameter Coal Mining Bits With Enhanced Structure For Drilling 3
